E-DAT Industry RJ12 coupler insert
Description
- unshielded class C RJ12 jack for mounting in IP67 flange housings of variants 1, 4, 5 and 14
- use for ingress protection IP65 in combination with Universal test jack
- compliance with class C according to ISO/IEC 11801, DIN EN 50173-1
- suitable for 10 MBit/s Ethernet (IEEE 802.3i)
- especially suitable for consolidation points and cross-connect cabling
- very compact design
- symmetrical structure, can be mounted in any position
Technical Data
General Data
M1
I1
C1
E1
coupler / adapter (FO)
unshielded
Copper
white
32.51 mm
15.6 mm
13.19 mm
1.28 in.
0.614 in.
0.519 in.
on housing
Transmission characteristics
IEEE 802.3af
Connections/interfaces
RJ12-jack
RJ12-jack
1
1
6P/6C
6P/6C
Electrical characteristics
max. 1 A at 60 °C
max. 60 V DC
max. 20 mOhm
min. 500 MOhm
min. 1000 V DC
Mechanical data
max. 20 N
min. 750
top
Materials and material properties
CuSn
Ni + Au (nickel-gold)
compliant
Environmental conditions
-40 °C
70 °C
-40 °F
158 °F
-40 °C
70 °C
-40 °F
158 °F
IP2X when plugged in
IPX0 when plugged in
Check US distributor inventory
Accessory of
Part number
1401A00810KI
4251394690735
