E-DAT modul 6x8(8) 3RU patch panel Cat.6A
Description
- module frame with 6 E-DAT modul individual modules
- Cat.6A component test according to ISO/IEC 11801, DIN EN 50173-1, ANSI/TIA-568.2-D and IEC 60603-7-51
- compliance with class EA according to ISO/IEC 11801, DIN EN 50173-1
- tested: Link to 500 MHz
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
- easy to install connection of 2 to 4-pair data lines AWG 26/1 - 22/1 and stranded wires with 7 copper conductors AWG 26/7 - 22/7 to BTR 8-fold insulation displacement connectors (IDC)
- marking of conductor assignment to T568A and T568B
- strain relief directly snapped on to stuffer cap of E-DAT modul
- 3RU module frame front made of silver anodized aluminum for mounting in 3RU assembly frame
- with label window for enclosed identification labels
- optional strain relief using cable ties
- grounding bolt M6 x 10 with nut and lock washer
Check US distributor inventory
Accessories
Part number
130922-02-E
4250184106180
Downloads
- 3D-Data - Registration required -
- Certificate (GHMT Type Approval - E-DATmodul - Cat.6A Certificate)
- Mounting note (Modulare Patchfelder)
- Mounting note (130910-I, 130910KI)
- Data sheet
