What is the difference between the RM21 and RM3?
The position of the output contact (socket), the RM21 is 2 storeys and the RM3 is 3 storeys.
RM3-2W 24 V DC
Description
Relay module for electrical isolation between logic and load.
- Connection with screw-type terminals
- pluggable relay
- with labeling field
Technical Data
General Data
24 V DC
17 mA
2 changeover contacts (DPDT)
AgNi 90/10
250 V AC
8 A
360 cycles/h
30 x 106 switching cycles
1 x 106 switching cycles
2 x 2.5 mm2
Red LED
15.5 x 75 x 65 mm
95 g
-20 °C to +55 °C
-25 °C to +70 °C
Check US distributor inventory
Accessories
Part number
11051025
4250184122333
Downloads
- Product information
- Data sheet
- ePLAN data - Registration required -
FAQ's
