LF-TO4 LON
Description
The LON module with 4 digital outputs was developed for decentralized switching tasks. It is suitable for switching electrical components, such as relays, contactors, HLK valves, etc. The 4 triacs can be controlled individually in a LON installation by means of standard network variables. The module has a manual control activated only in configured mode. In addition, an adjustable pulse/pause function is integrated. Suitable for decentralized mounting in serial sub-distributor.
- Connection with screw type terminal blocks
Technical Data
General Data
TP/FT-10, free topology
FT5000
78 KBit/s
24 V AC/DC +/- 10 % (SELV)
63 mA (AC) / 24 mA (DC)
100 %
550 ms
4 x digital outputs (triac)
24 V to 250 V AC
0.5 A / output
2.4 A / all outputs
Green and yellow LED
35 x 69.3 x 60 mm
104 g
-5 °C to 55 °C
-20 °C to 70 °C
IP40 / IP20
Check US distributor inventory
Accessories
Part number
11086213
4250184146995
Downloads
- Data sheet
- ePLAN data - Registration required -
- Brochure (LON I/O components)
- Brochure (Intelligent system components with integrated application software)
- REACh Statement
- 3D-Data - Registration required -
- Software (Template_LF-TO4)
- Software (LON Resource Files 1.32)
- Software (METZ Connect PlugIn LF-ALL 2.0.0)
- Mounting note (11086213, 1108621370)
- Mounting note (Safety Instructions multilingual )
- Software manual (LON Software-Handbuch)
