BMT-F-TO4 BACnet MS/TP

920128
909294
913310
910162
909297
Description

The BACnet MS/TP module with 4 digital triac outputs was developed for decentralized switching tasks. It is suitable for switching electrical components, such as relays, contactors, HLK valves, etc. The outputs can be switched by means of standard objects via a BACnet client. In addition, the outputs can be overridden manually by means of switches on the device. The module is addressed and the baud rate is set by means of two address switches on the front. Suitable for decentralized mounting on DIN TH35 rail according to IEC 60715 in electrical distribution cabinets.

  • Connection with spring clamp terminal blocks (push-in)
logo_btl logo_culs_listed

BACnet is a registered trademark of ASHRAE. ASHRAE does not endorse, approve or test products for compliance with ASHRAE standards. Compliance of listed products to the requirements of ASHRAE Standard 135 is the responsibility of BACnet International (BI). BTL is a registered trademark of BI.

Technical Data
General Data
BACnet MS/TP
00 to F9
RS485 (two-wire bus)
9600 to 115200 bit/s
24 V AC/DC +/- 10 % (SELV)
100 mA (AC) / 40 mA (DC)
100 %
4 digital outputs (triac)
24 V AC up to max. 250 V AC
0.5 A / output
0.8 A (less than 30 s)
10 A (less than 20 ms)
Green, red and yellow LED
35 x 69.3 x 60 mm
95 g
-5 °C to 55 °C
-20 °C to 70 °C
IP40 / IP20
Check US distributor inventory
Accessories
873544
Terminal block Type 259
908429
Power supply NG4-F 24 V DC
905881
Typ 135 RIACON 135_3.5
Accessory of
929544
BMT-RTR BACnet-Router
929546
BMT-F-RTR BACnet-Router
Part number
1108801370
4251394610030
